FORD 302 — 289-290 HP TURNKEY
FORD 302 — 330-331 HP TURNKEY

FORD 351W — 290-300 HP TURNKEY
FORD 351W — 325-330 HP TURNKEY
FORD 351W — 350-354 HP TURNKEY
FORD 351W — 360-365 HP TURNKEY



Pricing and torque ranges:

Ford 302 / 289-290HP: $3995 — 321 to 328 ft/lbs torque
(Cam has lots of vacuum for power brakes.
No need for stall speed converter.)

Ford 302 / 330 HP: $4195 — 348 to 350 ft/lbs torque
(Cam has vacuum for power brakes, great Old School Sound, stall speed converter required. Please call for full details.)

Ford 302 / 331HP: $4195 - 354 to 356 ft/lbs torque
(Cam has less vacuum for power brakes but still works, it's a little more aggressive cam. Still great Old School sound. Stall speed converter required. Please call for full details.)

351 WINDSOR Muscle car engines:

Ford 351W / 290-300HP: $4195 — 342-358 ft/lbs torque
(Cam has lots of vacuum for power brakes.
No need for stall speed converter.)

Ford 351W / 325-330HP: $4495 — 349-360 ft/lbs torque
(Cam has lots of vacuum for power brakes, etc. No stall speed converter required.)

Ford 351W / 350-354HP: $4695 — 373-376 ft/lbs torque
(This cam has a little less vacuum, but it's okay for power breaks, and it has the best Old School sound. Stall speed converter required.

Ford 351W / 360-365HP: $4895 — 377-382 ft/lbs torque
(This single patterned cam has very little vacuum, stall speed converter required. One of the best Old School sounds!)

The normal price of these engines is $100 more. Buy now to receive the special pricing listed here!

1015 SERIES 4 X 4 FORD 302

Available from (ask about upgrades):

Ford 302    — 300 to 315HP: 34;1-349 ft lbs torque $3995
(Cam has lots of vacuum for power brakes!)

Ford 302    — 326HP: 356-360 ft lbs torque $4095
(Cam has a LOT of vacuum)

Ford 302    — 330HP : 367-374 ft lbs torque $4195
(Less vacuum but still 4x4, a little more aggressive cam.)


Ford 351W — 280HP: 348-351 ft lbs torque $4195
(Best vacuum, great low end mid range and mileage.)

Ford 351W — 325HP: 375-378 ft lbs torque $4595
(Great vacuum, great low end mid range and mileage.)
This is one of the best for mid towing!

Ford 351W — 345HP 385-392 ft lbs torque $4695
(This one has great vacuum, great low end mid range and mileage.)
This is one of the best for mid to heavier towing!

Ford 351W — 353HP 388-395 ft lbs torque $4795
(Good vacuum, great low end mid range.)
This one is the best for mid-heavy towing and more torque!

Ford 351W — 360HP 398-408 ft lbs torque $5195
(Fair vacuum, good low end mid range and top end.)
This one is best for mid-heavy towing and more torque.
This engine is designed more for the "toy" application. This is a great Bronco toy engine, highly recommended.

(Please call for more 1015 Series 4X4 engines!)


Ask about our Fast Track Startup:
That means this engine can be
Real Ready to Run OUT OF THE BOX if you choose our Fast Track startup, which includes break in, super tuning, jetting, and more.

If you choose a Fast Track Start Up, we have special pricing right now!

Click HERE to learn more
Fast Track animationabout FAST TRACK, andFast Track animation
to view a sample video.


Video of Ford 302-290HP undergoing our Fast Track super tuningVIDEO: Click HERE to see our FAST TRACK startup in action on this engine! This is the Ford 302 290HP.


Ford302-290HP engine after Fast Track super tuningVIDEO: Click HERE to see the same engine after Fast Track Super Tuning, with open headers (awesome sound)!


Call NOW for FREE SHIPPING to Southern California! We offer super shipping prices to 48 states... see below for more info!


This Power2 engine combination has a great Old School sound. It is a great replacement mild street engine!

This engine has a MILD to ROUGH IDLE, SPEED PRO CAM that puts out 331HP at 5200 rpm and 342 ft lbs of torque. You will need an 1800 to 2200 Stall Speed Converter.

*Please note on the 289 to 290 HP, you do not need a stall speed converter. Please call us for details.*

This Power 2 Engine Combination is great for the everyday driver, in your MUSCLECAR, Street Rod, Hot Rod, Kit Car, Custom Truck, 4x4, or JEEP.

This Engine is a Seasoned Hand Picked Block.

Special features on this crate engine include these new parts and more: (Be sure to scroll down the page to see a more detailed listing.)

  • SEAL POWER or Speed Pro heavy duty pistons
    (piston application can vary depending upon horsepower)

    (higher horsepower engines also include ARP bolt kit)

  • NODULAR CRANK Pro Turn Micro Polish

  • Your choice of Edelbrock 600 to 750 CFM electric choke
    or Holly 600 to 750 CFM electric choke
    (some engines may require higher CFM carb)

  • Choice of 3 distributors:
    ProBillet Street HEI distributor is included,
    MSD 2 pack or MSD 6AL 3 pack is extra.

  • Plugs, Plug wires. Call for colors!

  • PER Pro 7" High Performance Harmonic Balancer

  • Chrome valve covers, Chrome pulley

  • New chrome air cleaner included. Custom air cleaners extra.

  • Water Pump, Fuel pump, 5 qt oil pan.
    (Custom oil pans are available for an extra charge.)

  • New Satin Aluminum intake manifold, plain (no name)
    OR new Edelbrock aluminum intake manifold.
    Polished or RPM dual plane intake manifolds are extra.

  • New Aluminum Timing cover.

  • This engine will run on Premium unleaded fuel.

  • Built from one of our Dyno tested and road proven packages. Your specific engine can be Dyno tested for an additional charge.

  • Call for info on flex plate or fly wheel.

  • Call for correct flex plate on automatics.

  • Call for info on standard transmission flywheels (4 or 6 speed, etc.)

  • Comes complete, intake to oil pan. Some assembly may be needed.

  • Call on Engine Colors.

  • Don't forget to call us for pricing on Fast Track Start up and Break-in!

What comes with your Power 2® engine?

Here's a listing of the parts and machine labor for your Power 2® engine from

Your Power 2 Engine® ENGINE PARTS include:

  • Power 2® SpeedPro cam kit (GREAT OLD SCHOOL SOUND!)
  • Power 2® hydraulic lifters, Seal Power
  • Power 2® spring set, heavy duty (940 series spring sets)
  • Satin aluminum intake manifold.
    (Polished or RPM dual plane intake manifold is extra.)
  • Heavy Duty Steel Stem intake valves
  • Heavy Duty Steel Stem exhaust valves
  • Premium positive valve seals, polyacrylate
  • Heavy Duty roller timing chain
  • Controlled internal oil system (a PER exclusive!)
  • Heavy duty stock or high volume Melling oil pump
  • Heavy duty Melling steel collar oil shaft
  • Heavy duty oil pickup screen
  • High quality American SpeedPro or Seal Power Heavy Duty pistons
  • P.E.R.® SpeedPro plasma molly rings
  • Brass freeze plug kit and oil gallery kit
  • High quality rear main seal, double lip polyacrylate
  • Fel Pro PermaTorque heavy duty gaskets and gasket set
  • King or Clevite main bearings, Real Tri metal, high quality
  • King or Clevite rod bearings, Real Tri metal, high quality
  • New rod nuts installed
  • Cam bearings, high quality 360 Set

Your Power 2 Engine® MACHINE LABOR includes:

  • P.E.R. 4-angle® valve job
  • Mill-matching surfaced heads
  • Heavy duty thick wall valve guides
  • Valve guides custom cut for posi-seals
  • Jet vat block and magnifluxing
  • Remove and replace all freeze plugs
  • Remove and replace gallery plugs
  • Remove and replace cam bearings
  • Custom centerline boring of block
    True 90 degree V8 centerline boring
  • Power hone to fit pistons and rings
  • Custom crank micro polish, radius oil holes
  • Rods pressed off, then heat fitted
  • Rods checked for alignment
  • Street Balancing and blueprinting




YOU WILL NEED to call us - 1-888-766-8044. There are too many variables on each application.

For any changes needed, just call and we will build a custom engine package for you with the horsepower you want. You can also change the color, choosing from over 25 different colors.

289 - 302 - 351c - 351m - 351w - 400m - 390 - 427 - 428 - 429 - 460 and more!

Call to order this engine:
Toll Free 1-888-766-8044
08:00am - 5:00pm Monday - Friday
09:00am - 1:00pm Saturday
Times listed are Arizona time (-7 GMT).
Arizona does not observe Daylight Savings Time. We are on MST all year round.

This Power Engine® is totally REBUILT in our Machine Shop by professionals from start to finish. The Power Engine® Performance Combination was developed from our over 45 years of experience on MUSCLECARS, STREET STRIPS, CUSTOM TRUCKS, 4x4s, and JEEPS. has built over 140,000 quality engines to date.

Warranty and Shipping Info:

This engine has a one year written warranty. Buyer pays actual shipping costs if unable to pick up engine from our shop in Phoenix AZ. Some state freight restrictions apply. Payment due in full prior to shipping. We accept Visa, Mastercard, Discover, money orders, cashier's checks, and direct deposit. (GET A DISCOUNT WITH A DIRECT DEPOSIT!) Business or personal checks must clear prior to shipping. Arizona residents must add 8.3% sales tax.
Please call for core requirements.
We accept Visa    We accept MasterCard    Discover credit card is accepted at Phoenix Engine
SPECIAL PROMO!! Call NOW for FREE SHIPPING to Southern California! We also offer super shipping rates to all 48 continental states.

Call today to order!
Toll Free: 1-888-766-8044

Disclaimer: Please note that some parts are based on availability. The brand names listed above are guidelines; the exact brand name may not be available at the time we build your engine. Pricing is deemed to be correct at time of posting, but is not guaranteed. It is listed as a guideline only. Please call us for complete pricing on the engine built to your specific requirements.
These engines are built from our Dyno tested and road proven packages in our shop.
Your specific engine can be Dyno tested individually for an additional cost.
