Phoenix Engine Rebuilders
Engine Components
What comes with your engine?
Here are descriptions of what is included with your rebuilt engine from Phoenix Engine Rebuilders

STOCK ENGINE PARTS include:
• PER ^® cam
• Hydraulic lifter set
• PER stock spring set
• Premium valve seals
• Steel gears and timing chain
• Controlled internal oil system
• Heavy duty oil pump
• Heavy duty steel collar oil shaft
• Heavy duty oil pickup screen as required
• High quality American made cast pistons
• PER^® single moly rings
• Steel freeze plugs
• High quality rear main seal (polyacrylate)
• PermaTorque head gaskets and gasket set
• Main bearings, tri metal
• Rod bearings, tri metal
• New rod nuts installed
• Cam bearings, high quality

Note that this is building your engine core. We can also build from our core bank at an additional charge.

STOCK ENGINE MACHINE LABOR includes:
• PER 4-angle^® valve job
• Mill heads as required
• Heavy duty thick wall valve guides
• Jet vat block and magnifluxing
• Remove and replace all freeze plugs
• Remove and replace gallery plugs
• Remove and replace cam bearings
• Custom bore block (Note: All boring of block is to best engine spec size)
• Power hone professional cross hatch
• Custom crank (Note: All grinds are to best engine specs)
• Polish crank shaft
• Rods pressed off, then heat fitted, installed
• Rods checked for alignment

Note that this is building your engine core. We can also build from our core bank at an additional charge.






Engine Components
What comes with your Power 1^® engine?
Here's a listing of the parts and machine labor for your Power 1^® engine from Phoenix Engine Rebuilders:

POWER 1^® ENGINE PARTS include:
• Power 1^® cam (Note: Be sure to see our Engine Pricing page for cam specs)
• Power 1^® spring set, heavy duty
• Premium positive valve seals, polyacrylate
• Double roller timing chain
• Controlled internal oil system (a PER exclusive!)
• Heavy duty, high volume oil pump
• Heavy duty steel collar oil shaft
• Heavy duty oil pickup screen
• High quality American made cast pistons
  Upgrade options on pistons: hypereutectic or forged)
• PER^® HP plasma moly rings
• Brass freeze plug kit
• High quality rear main seal double lip polyacrylate
• PermaTorque heavy duty gaskets and head gasket set
• Main bearings, tri metal, high quality
• Rod bearings, tri metal, high quality
• New rod nuts installed
• Cam bearings, high quality custom

Note that this is building your engine core. We can also build from our core bank at an additional charge.

UPGRADE OPTIONS:
• Valves: One-piece stainless intake
• Valves: One-piece stainless exhaust
• Valves: Valve sizes
• Stainless steel retainers
• Heavy duty valve keepers
• Moly push rods in sets
• Roller tip rocker arms
• Poly lock insets
• 5 qt oil pan
• 7 qt oil pan (recommended)
• Custom pickup screen

POWER 1^® ENGINE MACHINE LABOR includes:
• PER 5-angle^® valve job
  Upgrade Options:
  Please ask about our popular PER StreetPorting^® options and custom polishing for heads starting at $150, and intake manifolds starting at just $75!
  Screw-in studs and guideplates are highly recommended for upper end horsepower at 300, 350, 400+ HP.
• Mill-matching the heads
• Heavy duty thick wall valve guides
• Valve guides custom cut for posi-seals
• Jet vat block and magnifluxing
• Remove and replace all freeze plugs
• Remove and replace gallery plugs
• Remove and replace cam bearings
• Custom bore block (Note: all boring of block is to best engine spec size)
• Power hone to fit pistons and rings
• Custom crank (Note: All grinds are to best engine specs)
• Micro polish radius oil holes
• Rods pressed off, then heat fitted
• Rods checked for alignment and rebuilt

Note that this is building your engine core. We can also build from our core bank at an additional charge.






Phoenix Engine Rebuilders
Engine Components
What comes with your Power 2^® engine?
Here's a listing of the parts and machine labor for your Power 2^® engine from Phoenix Engine Rebuilders:

POWER 2^® ENGINE PARTS include:
• Power 2^® cam (Note: Be sure to see our Engine Pricing page for cam specs)
• Power 2^® hydraulic lifters
• Power 2^® spring set, heavy duty (900, 1000, 2000 series spring sets)
• Optional Heads:
  Dart I cast iron
  Dart II cast iron
  Dart IronEagle race head, or
  Edelbrock RPM all aluminum heads
• Optional Intake Manifolds:
  Edelbrock Performer
  Edelbrock RPM
  Edelbrock Victor
  Weiand Stealth
• One-piece stainless steel intake valves (small blocks only)
• One-piece stainless steel exhaust valves (small blocks only)
• Premium positive valve seals, polyacrylate
• Heavy duty roller timing chain (Optional True Roller or gear drive)
• Controlled internal oil system (a PER exclusive!)
• Heavy duty, high volume oil pump
• Heavy duty steel collar oil shaft
• Heavy duty oil pickup screen
• High quality American made hypereutectic pistons (availability limited for some engines)
• PER^® HP plasma moly rings
• Brass freeze plug kit
• High quality rear main seal double lip polyacrylate
• PermaTorque heavy duty gaskets and gasket set
• Main bearings, tri metal, high quality
• Rod bearings, tri metal, high quality
• New rod nuts installed
• Cam bearings, high quality custom

Note that this is building your engine core. We can also build from our core bank at an additional charge.

UPGRADE OPTIONS:
• Valves: One-piece stainless intake
• Valves: One-piece stainless exhaust
• Valves: Valve sizes
• Stainless steel retainers
• Heavy duty valve keepers
• Please ask about our popular PER StreetPorting^reg&; options and custom polishing for heads starting at $150, and intake manifolds starting at just $75
• Screw-in studs and guideplates are highly recommended for upper end horsepower at 300, 350, 400+HP
• Moly push rods, in sets
• Roller tip rocker arms
• Aluminum roller rocker valve train
• Poly lock insets
• True Roller or gear drives
• 5 qt oil pan
• 7 qt oil pan (recommended)
• Custom pickup screen

NOTE: We accommodate many custom upgrades. Be sure to ask for a customized estimate! Call 602 866-8044.

POWER 2^® ENGINE MACHINE LABOR includes:
• PER 5-angle^® valve job
  Upgrade Options:
  Please ask about our popular PER StreetPorting^® options and custom polishing for heads starting at $150, and intake manifolds starting at just $75!
  Screw-in studs and guideplates are highly recommended for upper end horsepower at 300, 350, 400+ HP.
• Mill-matching the heads
• Heavy duty thick wall valve guides
• Valve guides custom cut for posi-seals
• Jet vat block and magnifluxing
• Remove and replace all freeze plugs
• Remove and replace gallery plugs
• Remove and replace cam bearings
• Custom centerline boring of block (true 90 degree V8 centerline)
  Note: all boring of block is to best engine spec size.
• Power hone to fit pistons and rings
• Custom crank
  (Note: All grinds are to best engine specs)
  OPTIONAL:
  Replace rods with Scat, Crower, or Eagle
• Micro polish radius oil holes
• Rods pressed off, then heat fitted
• Rods checked for alignment and rebuilt
• Street balancing

Note that this is building your engine core. We can also build from our core bank at an additional charge.






Phoenix Engine Rebuilders
Engine Components
What comes with your Power 3^® engine?
POWER 3^® ENGINES include all of the items listed under Power 2^® and more. With a Power 3^® engine, your possibilities become unlimited.
Here's a listing of the parts and machine labor for your Power 3^® engine from Phoenix Engine Rebuilders:

POWER 3^® ENGINE PARTS include:
• Power 3^® cam
  (Note: Be sure to see our Engine Pricing page for cam specs)
• Power 3^® hydraulic lifters
• Power 3^® spring set, heavy duty (1000, 2000, 3000 series spring sets)
• Optional Heads:
  Dart I cast iron
  Dart II cast iron
  Dart IronEagle race head, or
  Edelbrock RPM all aluminum heads
• Optional Intake Manifolds:
  Edelbrock Performer
  Edelbrock RPM
  Edelbrock Victor
  Weiand Stealth
• One-piece stainless steel intake valves (valve types and sizes optional)
• One-piece stainless steel exhaust valves (valve types and sizes optional)
• Premium positive valve seals, polyacrylate and PER Power Viton Seals
• Heavy duty roller timing chain (Optional True Roller or gear drive)
• Controlled internal oil system (a PER exclusive!)
• Heavy duty, high volume oil pump
  (High pressure, high volume blueprinted oil pump)
• Heavy duty steel collar oil shaft
• Heavy duty oil pickup screen (See oil pan options)
• High quality American made hypereutectic pistons (Availability limited for some engines. Forged pistons availability limited.)
• PER^® High Performance plasma moly rings
• Brass freeze plug kit
• High quality rear main seal double lip polyacrylate
• PermaTorque heavy duty head gaskets and gasket set
  Optional one-piece pan gasket for early model engines, availability limited.
• Main bearings, tri metal, high quality - Competition series
• Rod bearings, tri metal, high quality - Competition series
• New rod nuts and rold bolts installed, Preferred ARP brand.
  Optional main cap stud kit and head stud kit.
• Cam bearings, high quality custom

Note that this is building your engine core. We can also build from our core bank at an additional charge.

UPGRADE OPTIONS:
• Valves: One-piece stainless intake
• Valves: One-piece stainless exhaust
• Valves: Valve oversize
• Stainless steel retainers
• Heavy duty valve keepers
• Please ask about our popular PER StreetPorting^$reg; options and custom polishing for heads starting at $150, and intake manifolds starting at just $75
• Screw-in studs and guideplates are highly recommended for upper end horsepower at 300, 350, 400+HP
• Moly push rods, in sets
• Roller tip rocker arms
• Aluminum roller rocker valve train
• Poly lock insets
• True Roller or Gear Drives
• 5 qt oil pan
• 7 qt oil pan (recommended)
• 8 qt to 10 qt+ oil pan
• Custom pickup screen
• One piece pan gasket for early model engines, availability limited.
• Main cap stud kit and head stud kit

NOTE: We accommodate many custom upgrades. Be sure to ask for a customized estimate! Call 602 866-8044.

POWER 3^® ENGINE MACHINE LABOR includes:
• PER 5-angle^® valve job
  Upgrade Options:
  PER 6 to 7+ angle^® (multi-radius cuts)
  Please ask about our popular PER StreetPorting^® options and custom polishing for heads starting at $250, and intake manifolds starting at just $100!
  Screw-in studs and guideplates are highly recommended for upper end horsepower at 375, 450, and 500 to unlimited HP.
• Mill-matching the heads and measure for blueprinting
• Heavy duty thick wall valve guides cut to match height and cut in bowl below valve for increased/improved air flow.
• Valve guides custom cut for posi-seals
• Jet vat block and magnifluxing
• Remove and replace all freeze plugs
• Remove and replace gallery plugs
• Remove and replace cam bearings
• Custom centerline boring of block (true 90 degree V8 centerline)
  Note: all boring of block is to best engine spec size.
• Power hone to fit each piston to each cylinder and rings
• Custom crank
  (Note: All grinds are to best engine specs)
• Micro polish radius oil holes and deburr crank
• Rods pressed off, then heat fitted and installed
• Rods checked for alignment and rebuilt to Power 3 spec
  OPTIONAL:
  Replace rods with Scat, Crower, or Eagle
• Custom spin balancing (heavy metal additional charge)

Note that this is building your engine core. We can also build from our core bank at an additional charge.












Phoenix Engine Rebuilders
Engine Components
What comes with your rebuilt engine for your restoration vehicle?
Your possibilities are unlimited.
Coming soon: a listing of standard parts and machine labor for your restoration vehicles's rebuilt engine from Phoenix Engine Rebuilders... stay tuned!
